Description
3 low-pass filters (80Hz, 100Hz, 120Hz) in SA3118 are available to choose according to different venues and music styles. There is also phase switch. All connectors and function buttons are on the back panel.
SA3118 subwoofer is with 1-way XLR for input and output. Signals caType
Active DSP-controlled Compact subwoofer
Frequency Response(-6dB anechoic chamber)
35Hz-150Hz
Maximum Calculated SPL/1M(Continuous/Peak)
128dB/134dB
LF Driver
Customized driver, 4” voice coil
AMPLIFIER
Amplifier Circuitry
Class D
Power(Peak)
2000W
Frequency Response(1W 8Ω 2ch)
20Hz-6KHz(±0.5dB)
Intermodulation Distortion
＜0.05%
Total Harmonic Distortion
＜0.05%
Protection
DC protection, short circuit protection, overheat protection, input overload protection, output overload protection, soft startup protection, overvoltage protection, undervoltage protection
Cooling System
Cooling with fans, air convection
DSP
Processor
96KHz signal sampling frequency,24bit precision
Presets
80Hz,100Hz,120Hz
Crossover
Controlled by DSP
Output/Input
Signal Input
1× female XLR
Signal Output
1× male XLR
Power Input
3 pin plug
Working Voltage
100V~130V or 220V~240V （±10%，50/60Hz）
Cabinet
Cabinet Material
CNC made of excellent wood
Cabinet Color
Black is standard and default color. Consult with Audiocenter sales team for other customized colors
Pole Mount
M20 base Φ35mm
Dimension(W×H×D)
520x700x618mm
Net Weight
43.0Kg
n be sent to different speakers for sound distribution.
