Description
Minimum System Requirements
• macOS: 10.8 Class Compliant
• PC: Windows 7, Windows Driver
• Standard USB 2.0 or USB-C Port
| Mic Input 1 (balanced XLR) | |
| Frequency Response | 20 Hz – 20 kHz (+0.1 dB) |
| Dynamic Range | 104 dB (A-weighted) |
| Signal-to-Noise Ratio | 104 dB (+1.0 dBu, A-weighted) |
| THD+N | 0.003% |
| Preamp EIN | -128 dBu (max gain, 150 Ω source, A-weighted) |
| Max Input Level | +1.5 dBu |
| Gain Range | 55 dB |
| Line Input 1 (balanced 1/4″ [6.35 mm] TRS) | |
| Frequency Response | 20 Hz – 20 kHz (+0.05 dB) |
| Signal-to-Noise Ratio | 101 dB (1 kHz, +4 dBu, A-weighted) |
| THD+N | 0.003% |
| Max Input Level | 16 dBu |
| Gain Range | 55 dB |
| Inst Input 2 (unbalanced 1/4″ [6.35 mm] TS) | |
| Frequency Response | 20 Hz – 20 kHz (+0.05 dB) |
| Dynamic Range | 100 dB (A-weighted) |
| Signal-to-Noise Ratio | 102 dB (+ 4 dBu, A-weighted) |
| THD+N | 0.004% |
| Max Input Level | 6 dBu |
| Input Impedance | 1 MΩ |
| Gain Range | 24 dB |
| Main Outputs, L and R (balanced, differential 1/4″ [6.35 mm] TRS) | |
| Frequency Response | 20 Hz – 20 kHz (+0.06 dB) |
| Dynamic Range / Signal-to-Noise Ratio | 102 dB (A-weighted) |
| THD+N | 0.005% |
| Max Output Level | +7 dBu (1 kHz, -1 dBFS) |
| Headphone Output (impedance-balanced 1/4” [6.35 mm] TRS) | |
| THD+N | 0.005% |
| Output Impedance | 10 Ω |
| General | |
| Power | USB-bus-powered |
| Dimensions (width x depth x height) | 8.0” x 6.0” x 2.76” (20.42 cm x 15.24 cm x 7.0 cm) |
| Weight | 2.0 lbs. 0.9 kg |
